1.1 Product Description
Horizontal and veruical burnlng tester is malnly used for plastic or fim under the speciied fre source direct bumina to measure thefre-resistant perormance of plastics, and determine its fire-resistant level. UL 94 is one of the most important test methods and standardsrelated to UL about fire safety. it is very important for plastics used in electrical industry, The test method is made based on the research olUL to plastic flame-resistant performance, which is not only applicable to the electrical industry, and many other areas, such as lightingeguipment, low-voltage appliances, household appliances, electrical machines, tools, instruments these equipment, and electricalconnections and other electrical and electronic products and component pats, their research, production, and quality control departmentsbut also for insulating materials, engineering materials and other solid combustible materials industry.
1.2 Related standards
UL 94
IEC 60695-11-10:2013
1.Controller: 7" colour touch screen and PLC control
2.Burner positioning: Pneumatic
3.lgnition time:0 ~99.99s arbitrarily settable, the residual flame time andafterglow time are automatically recorded
4.Flame height: 18~22mm
5.Angle conversion: push-pull device 90°,20°.45°
6.Burner: lmported from USA HUMBOLDT applying with the requirements of ASTM D 5025-99
7.Flowmeter:0~500mL/min
8.Burner inner diameter: 9.5mm.
•Overall Demensions:1050mm(W)x750mm(D)x1400mm(H)
•Power Supply:AC220V 50/60HZ 1A
•Gas source: Methane,air(provided by the customer)
